UV Shortpass Filters

Our UV shortpass filters are designed to have a very sharp transition between the reflect and pass bands while maintaining very high transmission at UV pass bands. The spectral transmission properties are uniform over the entire aperture of the filters. UV shortpass filters can be combined with our UV longpass filters in pairs to create a variety of transmission bands.

Description	Cut-off (nm)	Thickness (mm)	Item#
Description	Cut-off (nm)	Thickness (mm)	25mm dia.	50x50mm
Shortpass Filter / UV 265nm	265	1	XUS0265	ZUS0265
Shortpass Filter / UV 300nm	300	1	XUS0300	ZUS0300
Shortpass Filter / UV 325nm	325	1	XUS0325	ZUS0325
Shortpass Filter / UV 350nm	350	1	XUS0350	ZUS0350
Shortpass Filter / UV 350nm	350	1	XHS0350	ZHS0350
Shortpass Filter / UV 385nm	385	1	XUS0385	ZUS0385
Shortpass Filter / UV 385nm	385	1	XHS0385	ZHS0385
Shortpass Filter / UV 400nm	400	1	XHS0400	ZHS0400
